TEKBOX TBLM1 LISN Mate (Set)

960.-

Heute 09:35

9492, Eschen

Technische Merkmale:
4 pieces: 5 H LISN for Tektronix EMC pre-compliance
1 pieces: TBLM1 LISN Mate
2 pieces: AV-200N (Dummy Load)

5 H LISN
The EMI-LISN5UH is the TEKBOX TBOH01 5 H LISN. This device is required to set up conducted noise measurements of DC-powered devices and is designed to be used for EMC pre-compliance testing in the frequency range of 150 kHz to 110 MHz (according to the CISPR-25 standard, ISO 7637-2, ISO11452-2/4/5 and with limitations DO-160/ED-14G). The LISN is inserted into the supply line of the DUT (Device Under Test). Conducted noise that is present at the supply terminals of the DUT can be measured at the BNC connector using a spectrum analyzer or a measurement receiver. The source (supply) terminal and the DUT terminal are decoupled by a 5 H inductor.
TBLM1 LISN Mate
The TBLM1 is a companion device for LISNs, which splits the conducted noise signal into its common mode and differential mode components. The LISN Mate is connected to the output of a LISN inserted into the positive supply line and to a second LISN inserted into the negative supply line. The conducted noise signal at the output of a LISN is the sum of common mode and differential mode noise. The LISN mate splits it into the common mode and differential mode components, with each signal component available at a separate BNC port.
Frequency range: 30 kHz 110 MHz
Maximum RF level at any BNC port: 27dBm
Maximum DC current at any BNC port: 30 mA

AV-200N (Dummy Load)
D-original AV-DL-200-N DUMMY LOAD,
N male,
200 WATT (5 seconds), (35W continous)

Allgemeines:
# Abholung möglich.
# Verkauf wegen Auflösung eines Entwicklungsstandortes der RHIVA AG.
# Direktverkauf, ohne Zwischenhandel durch RHIVA AG

Zustand:
# Neuwertig, voll funktionsfähig
# Einsatz in Forschungs- und Entwicklungslabor (ESD-Raum)

Mehr Infos unter cdn.shopify.com/s/files/1/1826/1151/files/TBLM1_LISN_Mate_Manual.pdf?v=1616814078
