Aim TTI LD400P Programmable DC Electronic Load

1'320.-

Heute 08:28

9492, Eschen

Technische Merkmale:
Aim TTI LD400P Programmable DC Electronic Load

Beschreibung
Versatile solution for testing dc power sources
Constant current, resistance, conductance, voltage and power modes
Wide voltage and current range, 0 to 80V and 0 to 80A
400 watts continuous dissipation at 28°C (360W at 40°C)
600 watts short-term dissipation (up to 60 seconds)
Low minimum operating voltage of <1V at 40A
High resolution and accuracy for level setting
Built-in transient generator with variable slew
Current monitor output for waveform viewing
Variable drop-out voltage for battery testing
High resolution backlit graphic LCD with soft key control
Analogue remote control of levels and TTL control of on/off and transient switching
Front and rear input terminals (front terminals 30A max.)
Full bus control via USB, RS232 and LXI compliant LAN interfaces, with optional GPIB (LD400P)

Allgemeines:
# Abholung möglich.
# Verkauf wegen Auflösung eines Entwicklungsstandortes der RHIVA AG.
# Direktverkauf, ohne Zwischenhandel durch RHIVA AG

Zustand:
# Neuwertig, voll funktionsfähig
# Einsatz in Forschungs- und Entwicklungslabor (ESD-Raum)
