Tektronix INC P6021A AC und INC P6022 AC Current Probe

3'840.-

Heute 11:15

9492, Eschen

Tektronix INC P6021A AC Current Probe AND Tektronix INC P6022 AC Current Probe

Herstellerbeschreibung:
The P6021 and P6022 Current Probes provide versatile AC current measurements. Both probes provide accurate current measurements over a wide range of frequencies. The P6021 and P6022 allow current measurements without breaking the circuit by clipping onto the current carrying conductor. Shielded probe heads are not grounded when the slides are in their open positions, eliminating accidental grounding of the circuit under test.
Key performance specifications
P6021A
o 120 Hz to 60 MHz
o 10.6 A RMS, 250 A peak, 10 mA sensitivity
P6022
o 935 Hz to 120 MHz
o 2.12 A RMS, 100 A peak, 1 mA sensitivity
Key features
For 1 M inputs
Shielded probe head
AC only
Split core construction allows easy circuit connection
1.5 m (5 ft) cable
Applications
Motor drives
Power inverters/converters
Power supplies
Avionics
P6021A
For general purpose applications, the P6021A provides wide-band performance with excellent low-frequency characteristics. Bandwidth is 120 Hz to 60 MHz. The probe range is switchable between 2 mA/mV and 10 mA/mV.
P6022
With a head size of 0.47 in. x 0.25 in. (10 mm x 6 mm, about half the size of the P6021A) and a bandwidth of 935 Hz to 120 MHz, the P6022 is ideal for measuring currents in compact, high-performance circuits. Passive termination output is switchable between 1 mA/mV and 10 mA/mV.

Allgemeines:
# Abholung möglich.
# Verkauf wegen Auflösung eines Entwicklungsstandortes der RHIVA AG.
# Direktverkauf, ohne Zwischenhandel durch RHIVA AG

Zustand:
# Neuwertig, voll funktionsfähig
# Einsatz in Forschungs- und Entwicklungslabor (ESD-Raum)

Mehr Infos unter www.tek.com/en/datasheet/ac-current-probes
