MDL Music - Slew Rate - Eurorack

159.-

26.07.2026

3414, Oberburg

The Slew Rate module is a voltage controlled slew limiter and modulation source. The core idea behind this module is inspired by many popular modules including the Makenoise Maths and the Befaco Rampage.

At the modules' heart is a voltage controlled slew limiter, whose output is a copy of the input voltage except with any sharp steps replaced by smooth ramps, with a rate set by the front panel Rise and Fall controls as well as the corresponding control voltages. When used on pitch CV, the slew limiter creates a glide effect.

Additional logic circuitry turns the Slew Rate into a versatile modulation source. By feeding a signal to the Gate, the module becomes a voltage controlled envelope generator, with the attack time set by Rise, an optional Sustain phase, and the decay time by Fall.

Black Enig circuit board professionally soldered in the reflow process. calibrated and tested.

Inputs: IN / GATE / CV RISE / CV FALL

Outputs: OUT

Size: 8HP
2mm Aluminium Panel

Knobs: Black/Gold/Silver Aluminium

Inkl. Ribbon Cable and Screws

1 Year Warranty
