Teledyne LeCroy MDA803A Motor Drive Analyzers Oszilloskop

16 700.-

Oggi 11:17

9492, Eschen

Teledyne LeCroy MDA803A Motor Drive Analyzers
350 MHz, 8 Ch, 12-bit, 10 GS/s, 50 Mpts/Ch Motor Drive Analyzer

Spezifikations
Motor Drive Analyzers provide complete three-phase power analysis from motor drive input through motor mechanical output, with results in a convenient Numeric table format. Motor speed, position, and torque integration are the most complete available. Long memory, per-cycle synthesized Waveforms and Zoom+Gate mode provide powerful dynamic drive and motor analysis. 8 analog input channels (MSO optional) with high resolution (12-bits), sample rate (up to 2.5 GS/s), bandwidth (up to 1 GHz) and memory (up to 250 Mpt/ch) provide unique capability to perform complete system debug on the motor drive power section, motor mechanical performance, and embedded drive control system operation.

Key Features:
Complete Motor Drive System Debug and Validation in One Instrument
Three-Phase Power Measurements; Real, Apparent, Reactive Power
Efficiency Measurements
User-Configurable Power Table
Two- and Three-Wattmeter Methods Supported
Per-Cycle Time-Correlated Waveforms From Power Values
Dynamic Drive Response Analysis, From Startup To Overload
Unique Zoom+Gate Mode
Line-Line To Line-Neutral Voltage Conversion
1000 VRMS Isolation with HVD Series Differential Probes
Easily Interface Other Current Measurement Devices
Complete Motor Integration (Torque, Speed, Position)
Flexible Setup Capability Graphical User Interface

Allgemeines:
# Abholung möglich.
# Verkauf wegen Auflösung eines Entwicklungsstandortes der RHIVA AG.
# Direktverkauf, ohne Zwischenhandel durch RHIVA AG

Zustand:
# Neuwertig, voll funktionsfähig
# Einsatz in Forschungs- und Entwicklungslabor (ESD-Raum)
