Sommerkamp TS-800
295.-
Gestern 06:49
8750, Glarus
Sommerkamp TS-800 in originalen Schachtel und mit zusätzlichem Mikrofon.
SPECIFICATIONS
GENERAL
Type: Amateur VHF transceiver
Frequency range: TX: 140.000-149.9875 MHz
RX: 140.000-149.9875 MHz
Tuning steps: 12.5 KHz
Frequency stability: ±? ppm
Mode: FM
Channels / memory management:
Repeater shift / offset: ±600 KHz
Power supply: 11-16 VDC
Current drain / power consumption: RX: 500 mA
TX: Max 12 A
Antenna impedance / connector: 50 ohms / SO-239
Dimensions (W*H*D): 156*61*290 mm (6.14*2.4*11.42")
Weight: ? Kg (? lb)
Other features: CTCSS/PL with "answer back". 1750 and 1800 Hz tone call.
RECEIVER SECTION
Receiver system: Double conversion superheterodyne
1st IF: 17.09 MHz
2nd IF: 455 KHz
Sensitivity: 1 uV (No reference)
Selectivity: 15 KHz (-6 dB)
Image rejection:
AF output power / speaker: 2 W at 10% distortion / 8 ohm
External speaker connector: 3.5 mm, 8 ohm
TRANSMITTER SECTION
RF output power:
High Low
2 m: 50 W 5 W
Modulation system:
Max FM deviation (Factory set): ±5 KHz
Spurious emissions: Better than -60 dB
Microphone impedance / connector: 500-1000 ohm / 8-pin
Microphone input level: ? mV
MISCELLANEOUS
Manufactured: Japan, 197x-198x (Discontinued)
Additional info: The microphone is switchable for use as a speaker-mike, which is
very useful in a noisy vehicle.
Verkaufe nur an lizenzierte Amateurfunker.
Stichworte, da die Rubrik "Funk" fehlt:
Amateurfunk Amateur-Funk Funkamateur Funk-Amateur Funk CB-Funk funken
Kurzwelle Kurzwellen KW UHF VHF HF SHF Empfänger Sender Receiver Transceiver TRX RX Antennen Antenne Morsen Morse CW Telegraphieren Telegrafieren Telegraphie Telegrafie
SPECIFICATIONS
GENERAL
Type: Amateur VHF transceiver
Frequency range: TX: 140.000-149.9875 MHz
RX: 140.000-149.9875 MHz
Tuning steps: 12.5 KHz
Frequency stability: ±? ppm
Mode: FM
Channels / memory management:
Repeater shift / offset: ±600 KHz
Power supply: 11-16 VDC
Current drain / power consumption: RX: 500 mA
TX: Max 12 A
Antenna impedance / connector: 50 ohms / SO-239
Dimensions (W*H*D): 156*61*290 mm (6.14*2.4*11.42")
Weight: ? Kg (? lb)
Other features: CTCSS/PL with "answer back". 1750 and 1800 Hz tone call.
RECEIVER SECTION
Receiver system: Double conversion superheterodyne
1st IF: 17.09 MHz
2nd IF: 455 KHz
Sensitivity: 1 uV (No reference)
Selectivity: 15 KHz (-6 dB)
Image rejection:
AF output power / speaker: 2 W at 10% distortion / 8 ohm
External speaker connector: 3.5 mm, 8 ohm
TRANSMITTER SECTION
RF output power:
High Low
2 m: 50 W 5 W
Modulation system:
Max FM deviation (Factory set): ±5 KHz
Spurious emissions: Better than -60 dB
Microphone impedance / connector: 500-1000 ohm / 8-pin
Microphone input level: ? mV
MISCELLANEOUS
Manufactured: Japan, 197x-198x (Discontinued)
Additional info: The microphone is switchable for use as a speaker-mike, which is
very useful in a noisy vehicle.
Verkaufe nur an lizenzierte Amateurfunker.
Stichworte, da die Rubrik "Funk" fehlt:
Amateurfunk Amateur-Funk Funkamateur Funk-Amateur Funk CB-Funk funken
Kurzwelle Kurzwellen KW UHF VHF HF SHF Empfänger Sender Receiver Transceiver TRX RX Antennen Antenne Morsen Morse CW Telegraphieren Telegrafieren Telegraphie Telegrafie
- Preis CHF
- 295.-
- PLZ
- 8750
- Versand verfügbar
- Ja
