Li-ion Lithium Battery (NMC-Chemie) 3.7 V Cell 40 Ah

29.-

Gestern 01:57

3253, Schnottwil

Allgemeine Informationen

Modell: YUASA LEV40 Cell

Elektrische Spezifikationen

Nominal voltage: 3.75V

Operating voltage range: 2.75V to 4.1V

1-hr rate typical Capacity 25°C: 40Ah

Continuous current: 250A

Physikalische Abmessungen & Gewicht

Length: 151

Width: 44

Height (over terminals): 111

Mass: 1.3kg

Anschluss & Montage

Male threaded terminal: M8

Torque: 9-13Nm

Spannungsgrenzen beim Laden

Charge voltage limit at 25°C V (continuous): 4.1V

Charge voltage limit at 25°C V (60mSec): 4.2V

Charge termination threshold current: <0.5A

Ladeströme nach Temperaturbereichen

Maximum Charge Current: 10A

Charge -1C (-10°C - 25°C): 25A

Charge +10°C to +10°C): 40A

Charge +10°C to +40°C ('±): 100A

Charge +40°C to +45°C: 200A

Charge +45°C to +55°C: 250A

Charge +55°C to +60°C: 200A

Lebensdauer & Testbedingungen

100% DOD @ 25°C, Assuming: 2500 (Zyklen)
